SPECS
- Builder: Bruckmann Yachts (CAN)
- Designer: Mark Ellis
MEASUREMENTS
- Length Overall: 46.42 ft
- Length Waterline: 46 ft
- Max Draft: 4' 11"
- Cabin Head room measure: 6' 3"
- Beam Measure: 15' 0"
ENGINE(S)
TANKS
- Fresh Water Tanks: 1 (150 Gallons)
- Fuel Tanks: 1 (500 Gallons)
Accommodations
- Number of cabins: 2
- Number of heads: 1
STRUCTURE AND HULL CONSTRUCTION
- Fiberglass roving and unidirectional E-glass reinforced structural grid with limber holes providing longitudinal floors forming engine beds with transverse frames
- Vinylester resin throughout
- Core-Cell cored fiberglass molding
- Extra reinforcing as required
- Core removed in way of all throughhulls, shaft logs, rudder ports and centre line
- FRP centerline prop protecting skeg
- Awlgrip hull finish
DECK CONSTRUCTION
- Single piece foam cored fiberglass molding with non-skid on all working surfaces
- Awlgrip Sand-textured non-skid surfaces finished in choice of color
- Core phased out in way of all deck fittings
- Overlapping hull to deck joint bonded and fastened every 4 inches
- Extended Swim platform with swim ladder
- Transom door to platform
MECHANICAL
- Caterpillar C18 1136 hp. diesel engine
- Optional twin Caterpillar C8.7 641 hp. diesel engines
- Digital engine instrument panel and controls
- Dual density engine sound insulation
- Isolated bilge area under engine(s)
- Raw water cooled exhaust with muffler
- Aqua Met propeller shaft(s)
- 5 blade bronze propeller(s)
- Sidepower 24v variable speed bow and stern thrusters with batteries
- Dripless shaft seal(s)
- Bronze rudder(s)
- Dual engine room ventilation
- 2 250 US gal vented fuel tanks plus 100 US gal daytank
- Dual Racor fuel filters
- Raw water intake strainers
- Hydraulic steering
- Trim tab system
- Mahogany rimmed Stainless steel steering wheel
PLUMBING
- Pressure water with hot and cold faucets in heads, shower and galley
- Hot and cold cockpit shower
- Water heater, 20 gallon, 240V and engine heat exchanger
- 2 x 100 US gallon water tanks with level indicator at helm
- Polished stainless steel sinks in galley and head
- Single lever chromed brass faucets
- Rigid colour coded PVC plumbing
- Vacuflush head systems with 50 US gallon holding tank capacity
- Holding tank overboard discharge
- 4 automatic bilge pumps
- Integrated manual bilge pump
ELECTRICAL
- All wiring sized and colour coded to ABYC specs.
- 24V DC custom distribution panel with digital meters
- 125v/240v 50 amp system
- AC custom power distribution panels with digital meters and polarity indicator
- 50 amp shore power fore and aft with 25 foot cord
- 110V outlets in galley, head, forward cabin and engine room with ground fault
- AGM engine starting batteries
- 24v 400 amp hour AGM house battery bank
- 24v 4000w Inverter/battery charger
- Front opening 24V refrigerator
- Separate top access 24V freezer
- Two burner induction ceramic cooktop
- Microwave/convection oven
- 38000 BTU total air conditioning in staterooms and pilothouse
- Chrome LED lighting throughout interior
- Chrome reading lights in staterooms and saloon
- Fusion stereo speakers with speakers in saloon and cockpit
- LED engine room lighting
- 3 windshield wipers/washers with independent on/off switches at helm
- Running lights and anchor light
- Courtesy lights in cockpit, saloon and interior
- Fire extinguishers in cabin and cockpit
INTERIOR
- Main bulkheads and faces laminate or veneer covered marine plywood fibreglassed to hull and deck
- Satin varnished interior wood trim
- Cabin and locker doors wood framed
- Varnished teak and holly cabin sole
- Removable overhead panels in satin white
- All exposed interior fiberglass in locker interiors covered with ply, cedar or gelcoat
- Spacious forward cabin with island double berth and overhead aircraft lockers, bureau with drawers and hanging locker
- Ensuite head with large separate shower
- Corian countertops in galley and head with under mounted sinks
- Double sink at galley with drawers for utensils.
- Sliding door storage outboard of galley.
- Tilt out trash bin under sink, dish storage locker above
- Galley is open to pilothouse for greater light and ventilation
- All latches, hinges, catches and pulls are chromed bronze or brass
- Mirrors in heads and staterooms
- 5 inch foam upholstered cushions in helm area and 6 inch foam in V berth
DECK
- Double bow fitting with twin anchor rollers
- Bow eye at waterline
- 24v Windlass
- 6 stainless steel 12 inch mooring cleats
- 6 custom inline toe rail chocks
- Stainless steel bow rail extending aft to cockpit
- Large molded hull rub rail at chine aft with stainless steel half round
- Varnished solid teak caprail on bulwarks extending aft to cockpit
- Varnished teak cabin house nosing
- Stainless steel striker on hull at sheer to protect teak caprail
- 2 stainless steel handrails on hardtop
- 2 stainless steel handrails on cabin top
- 6 stainless steel opening ports with screens
- Large windows in pilothouse
- Large sliding door to aft cockpit from enclosed pilothouse
- 6 Stainless steel overhead hatches with OceanAir screens and shades
- Settees port and starboard in pilothouse with hinged storage access
- Stidd Pedestal mount helmsman and co-pilot seats forward
- Chart table at co-pilot seat
- Dining table to port
- Overhead handrail in pilothouse
- Hatches in pilothouse floor for engine access, power raised
- Hatches in cockpit sole for storage and access
- 4 inch foam upholstered cockpit cushions
- 6 fenders and dock lines
Disclaimer
The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
